Trapezoidal Thread Gauge

Name: Trapezoidal Thread Gauge
Brand: JUPITER TRADERS
Price: 1000 INR
Availability: InStock

Price 1000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Trapezoidal Thread Gauge Specification

Measuring Range
Varies by thread size

Case
Hard protective case

Outer Size
As per required gauge size

Thread
Trapezoidal (DIN 103 standard)

Display
None (Mechanical Gauge)

Usage
Industrial

Material
Stainless Steel

Product Type
Trapezoidal Thread Gauge

Grade
Industrial

Color
Silver And Black

Application
Measurement and inspection of Trapezoidal threads

Accuracy
High precision; conforms to ISO and DIN standards

Customization
Available for special thread forms

Usage
Suitable for quality control, tool rooms, manufacturing units

Surface Finish
Precision ground and lapped

TPI (Threads Per Inch)
Available as per requirement

Standards
DIN 103, ISO 2901/2904

Gauge Type
GO / NO-GO plug or ring gauge

Rust Resistance
Anti-corrosive finish

Markings
Size and specification permanently marked

Hardness
HRC 58-62

Thread Angle
30 degrees (as per Trapezoidal standard)

Trapezoidal Thread Gauge Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
300000 Pieces Per Month

Delivery Time
1-2 Days

Main Domestic Market
All India

About Trapezoidal Thread Gauge

We are offering a Trapezoidal Thread Gauge, which is used for translation motion in machine tools like lead screws, where rapid movement is required or in screw jacks, where load to be shared is more. This gauge comes in 2 shapes: square thread forms and trapezoidal thread forms. The majority of lead screw designs for power transmission employ trapezoidal threads gauge because they are more straightforward to manufacture and have better load capabilities than square-threaded screws.

Precision Ground & Lapped for Ultimate Accuracy

Our Trapezoidal Thread Gauges are finished with precision grinding and lapping, guaranteeing high accuracy for industrial inspection needs. Their robust build and adherence to ISO and DIN standards ensure reliable, repeatable measurements for quality thread assessment across various applications.

Corrosion-Resistant with Clear Markings

Designed for longevity, each gauge features an anti-corrosive finish and is clearly marked with size and specifications to withstand tough industrial environments. The rust-resistant surface and permanent identification add convenience and durability to your gauge investment.

Customized Solutions and Wide Compatibility

Available in silver and black, with measuring ranges tailored to the thread size, these gauges accommodate different TPI requirements and thread angles. Customization options allow for the manufacturing of special thread forms, ensuring your specific industrial inspection needs are met efficiently.

FAQ's of Trapezoidal Thread Gauge:

Q: How is the Trapezoidal Thread Gauge used for measurement and inspection?

A: The Trapezoidal Thread Gauge is a mechanical tool designed for measuring and inspecting Trapezoidal screw threads. It helps verify whether the internal or external threads meet the required DIN 103 and ISO standards by utilizing the GO/NO-GO method, ensuring only compliant threads pass quality control.

Q: What advantages does the precision ground and lapped surface finish offer?

A: A precision ground and lapped surface finish enhances measurement accuracy and repeatability by providing smooth, wear-resistant surfaces. This finish minimizes gauge friction and ensures optimal contact with threads, leading to dependable performance in industrial settings.

Q: When should I use a GO vs. a NO-GO gauge for checking threads?

A: A GO gauge is used to confirm that a thread meets minimum tolerance requirements and can be assembled correctly, whereas a NO-GO gauge ensures the thread does not exceed maximum tolerance limits. Typically, both are used in sequence during quality assurance checks.

Q: Where can the Trapezoidal Thread Gauge be applied?

A: This gauge is ideal for use in factories, workshops, and inspection labs where high-precision measurement of Trapezoidal threads-particularly in mechanical, automotive, and manufacturing industries in India-is essential for product quality.

Q: How does the anti-corrosive finish benefit the gauge in industrial environments?

A: The anti-corrosive finish protects the gauge from rust and environmental deterioration, extending its usable lifespan and ensuring it retains high measurement accuracy even with frequent industrial use.

Q: What is the process for customizing the gauge for special thread forms?

A: Clients can request customization by providing specific thread form details, such as TPI, size, or non-standard dimensions. The manufacturer will then fabricate the gauge to those exact specifications, adhering to the required standard guidelines.

Q: Why is permanent marking of size and specification important on these gauges?

A: Permanent markings make it easy to identify the gauge's size and specifications at a glance, reducing the risk of using the wrong gauge during inspection and ensuring efficient workflow in busy industrial settings.
