Variable Spline Indicator Plug Gauge with Setting Master Ring

Name: Variable Spline Indicator Plug Gauge with Setting Master Ring
Brand: JUPITER TRADERS
Price: 10000 INR
Availability: InStock

Price 10000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Variable Spline Indicator Plug Gauge with Setting Master Ring Specification

Outer Size
Diameter as per spline specification (can be customized)

Thread
Non-threaded (Spline Profile)

Glass Size
Dependent on Indicator size (typically 50-60 mm)

Display
Dial Indicator (Analogue)

Case
Wooden or Hard Plastic Protective Case

Measuring Range
Customizable, typically 10 mm to 120 mm or as per spline size

Sensor Type
Indicator with Dial Gauge (Analogue)

Usage
Industrial

Material
Stainless Steel

Working Presssure
Manual Inspection (No working pressure)

Seal Material
Hardened Steel

Product Type
Variable Spline Indicator Plug Gauge

Grade
Precision - IS Standard

Application
Measuring and checking the effective diameter of splined holes or components

Color
Black

Accuracy
0.001 mm (based on indicator precision)

Master Ring Hardness
Above 60 HRC

Profile Compliance
DIN, ANSI, or IS standards as required

Setting Master Ring Included
Yes, with matched calibration certificate

Repeatability
High repeatability suitable for mass inspection

Spline Compatibility
External and internal involute splines

Packaging
Individually boxed for safe transport

Corrosion Resistance
Anti-corrosive coating for durability

Operating Temperature
0°C to 45°C

Handle
Ergonomic insulated handle

Custom Markings
Available upon request

Indicator Resolution
0.01 mm or better

Gauge Type
Go/No-Go design with indicator feedback

Surface Finish
Mirror Finish, Ground

Calibration Standard
Supplied with traceable calibration certificate

Variable Spline Indicator Plug Gauge with Setting Master Ring Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1-7 Days

About Variable Spline Indicator Plug Gauge with Setting Master Ring

Access precision with the Variable Spline Indicator Plug Gauge featuring a Setting Master Ring-an uncommon solution for inspecting both external and internal involute splines. Praiseworthy in accuracy, this GO/NO-GO gauge offers a mirror finish, ground surface, and an anti-corrosive, durable stainless steel build. Jump on scarce opportunities for error-free measurement with indicator feedback and a matched calibration certificate. Designed with a terrific ergonomic insulated handle and superb repeatability, it complies fully with DIN, ANSI, or IS standards. Exclusively distributed, ready for industrial-grade demands in India.

Applications and Key Features of the Variable Spline Indicator Plug Gauge

The Variable Spline Indicator Plug Gauge with Setting Master Ring is used for measuring and verifying the effective diameter of splined holes or components with superior repeatability. It suits mass inspections in industrial applications, fitting both external and internal involute splines. Key features include a precision indicator with 0.01 mm resolution, GO/NO-GO feedback design, ergonomic insulated handle for comfort, anti-corrosive stainless steel body, and mirror ground finish. Custom markings are available, ensuring exact compliance with DIN, ANSI, or IS standards.

Packaging, Payment Options, and Sample Policy Details

Each Variable Spline Indicator Plug Gauge is individually boxed, ensuring safe transport and maintaining market value. Stock is ready and available for immediate dispatch. Products are packaged in either sturdy wooden or hard plastic protective cases as per requirements. Flexible payment terms are offered to accommodate distributors, suppliers, and traders. A sample can be provided upon request at the list price, giving buyers assurance in product quality and suitability before bulk ordering.

FAQ's of Variable Spline Indicator Plug Gauge with Setting Master Ring:

Q: How does the Variable Spline Indicator Plug Gauge improve inspection accuracy?

A: This plug gauge combines GO/NO-GO design with a high-resolution indicator (0.01 mm or better) to give immediate, reliable feedback about spline dimensions, ensuring precision during inspection.

Q: What spline profiles can this gauge check?

A: The Variable Spline Indicator Plug Gauge is compatible with both external and internal involute spline profiles, adaptable to DIN, ANSI, or IS standards as required.

Q: Where is the Variable Spline Indicator Plug Gauge most commonly used?

A: It is widely applied in industrial settings for mass inspection of splined components, suitable for manufacturers, quality control labs, and engineering workshops.

Q: When should I request custom markings or sizing?

A: Custom markings and sizing are recommended if you need the gauge tailored to unique spline profiles or if specific identification and traceability are required for your inspection process.

Q: What are the packaging and delivery standards for this product?

A: Each gauge is individually boxed, offered in either a wooden or hard plastic case, ensuring its pristine condition and readiness for use upon arrival.
