Rd Round Trapezodial Thread Plug Gauge

Name: Rd Round Trapezodial Thread Plug Gauge
Brand: JUPITER TRADERS
Price: 550 INR
Availability: InStock

Price 550 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Rd Round Trapezodial Thread Plug Gauge Specification

Sensor Type
Thread Plug Gauge

Thread
ISO Metric Round (Rd) Trapezoidal Thread

Case
Protective industrial storage case

Measuring Range
Available in multiple standard diameters and pitches

Outer Size
Custom as per thread size (e.g., M10, M18, etc.)

Display
Analog (Go/No-Go ends)

Usage
Industrial

Size
M6 x 1

Material
Stainless Steel

Product Type
Thread Plug Gauge

Grade
Precision Engineering Grade

Application
Checking and verifying Rd trapezoidal internal threads in mechanical parts or fittings

Accuracy
Manufactured to applicable ISO/DIN or customer standard tolerances

Hardness
Surface hardened to 58-62 HRC

Standards Compliance
Conforms to DIN 405 / DIN 103 or as specified

Thread Profile Angle
30° (Standard for Rd trapezoidal threads)

Handle Type
Ergonomic, knurled handle for easy grip

Marking
Laser engraved size and standard marking

Usage
Widely used in machine shops, production, and quality-control environments

Surface Finish
Polished and anti-corrosive finish

Go/No-Go Ends
Supplied with both Go and No-Go ends for precise inspection

Rd Round Trapezodial Thread Plug Gauge Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1-7 Days

About Rd Round Trapezodial Thread Plug Gauge

Experience an elite level of precision with the Rd Round Trapezoidal Thread Plug Gauge, offered at a special rate for distinguished industrial users. This paragon of thread measurement comes with exclusive Go/No-Go ends to ensure accurate inspection of Rd trapezoidal internal threads. Each gauge is manufactured from stainless steel, surface hardened to 58-62 HRC, and features a polished, anti-corrosive finish. The ergonomic, knurled handle delivers easy grip, while laser-engraved markings ensure permanent identification. Conforming to DIN 405/DIN 103, it's the premier choice for engineers seeking accuracy, reliability, and premium quality in thread verification across multiple thread sizes. Get unmatched durability, standards compliance and elite storage with its industrial case-perfect for the distinguished professional in manufacturing, distribution, or supply across India.

Versatile Application Across Industries

The Rd Round Trapezoidal Thread Plug Gauge is crafted for precision usage in industrial environments. Ideal for verifying and inspecting Rd trapezoidal threads in mechanical parts and fittings, it is suitable for engineering workshops, manufacturing plants, and quality control laboratories. Perfect for commercial applications demanding high standards, this distinguished gauge excels in machinery assembly, parts verification, and inspection tasks. Its robust build and ergonomic finish make it a preferred tool among elite professionals performing regular thread accreditation and maintenance operations.

Exclusive Sample Policy & Certifications

Discover peace of mind with our streamlined sample policy: stock-ready units are available at a competitive list price, with freight options clearly stated during order placement. All Rd Round Trapezoidal Thread Plug Gauges are provided with essential certifications, assuring compliance with ISO/DIN or specified standards. We extend flexible payment terms for seamless procurement, catering to distinguished buyers and elite distributors alike. Get your samples quickly and efficiently-enabling confident, informed purchasing decisions for your commercial and industrial needs.

FAQ's of Rd Round Trapezodial Thread Plug Gauge:

Q: How does the Go/No-Go feature work on the Rd Round Trapezoidal Thread Plug Gauge?

A: The Go/No-Go ends provide a straightforward pass/fail inspection method. The 'Go' end should fit into the threaded component, verifying it meets minimum dimensional requirements, while the 'No-Go' end should not fit, ensuring the thread does not exceed maximum tolerance-ensuring rapid, accurate thread assessment.

Q: What makes this gauge suitable for commercial and industrial usage?

A: This gauge is engineered from durable stainless steel, surface hardened for enhanced longevity and resistance to wear. Its ergonomic handle, anti-corrosive finish, and compliance with ISO/DIN standards make it ideal for frequent use in demanding environments such as manufacturing, inspection, and quality control operations.

Q: When should I use the Rd Round Trapezoidal Thread Plug Gauge?

A: Use this gauge whenever you need to verify the thread integrity of internal Rd trapezoidal threads in mechanical parts or fittings, especially during assembly, production, or quality assurance processes, to ensure components meet industry and customer requirements.

Q: Where can I obtain certification details for these gauges?

A: Certification details are supplied with each gauge, verifying compliance with standards like DIN 405/DIN 103 or customer specifications. For further certification information, you may also consult with the distributor or supplier at the time of purchase.

Q: What is the process for obtaining a sample or placing an order?

A: You can request a sample from stock-ready inventory at the current list price, with information on freight and payment terms provided upfront. Orders can be coordinated directly with the distributor, supplier, or trader, ensuring swift and reliable delivery across India.
